Weather-resistant plastic cover in 3 different colours
24V technology
Connection cable
Encapsulated gear
Self-locking steel spindle
Integrated mechanical limit stop
Super fast
Super fast, incredible 11 seconds for 90°, so up to 70% faster than conventional swing gate operators
Double security
The integrated encoder measures the rotation speed. Furthermore the control unit monitors the force. The result: maximum security
Weather-resistant plastic cover in 3 different colours
The operator seriers consits of weather-resistant plastic cover with a special UV-protection. Standard available in 3 different colours. Anthracite grey (similar RAL 7016), pure white (similar RAL9010) and moss green (similar RAL 6005)
24V technology
A 24V DC motor ensures even smoother running and smooth door movement
Connection cable
A 4-pin cable for motor and encoder, which is routed to the motor through the column-side pivot pin (hollow shaft)
Encapsulated gear
The encapsulated housing ensures even smoother running and reliability.
Self-locking steel spindle
The self-locking spindle ensures that the gate is locked in any position. This eliminates the electric lock.
Integrated mechanical limit stop
Serienmäßig interner mechanischer
Anschlag für Offen.
Für Geschlossen optional
Control unit ST 24
Large, illuminated LC-Display (2 x 16 characters)
Clear text menu programmable through 4 buttons
Self-monitoring of the photocell
Downloadable memory of the last 800 cycles
Automatic motor detection
Optionally with emergency battery in the event of a power failure
Integrated radrio receiver RS868
Up to 40 transmitter codes can be learned
Integrated courtyard light output (24V, 4W for connection of a relay)
Output for a 24V signal lamp
Technical data
Gate weight
200kg
Max. leaf width
2,5m
Travel speed
30mm/s
Usage
Private area
Power supply
24V
Working stroke
380mm
Max. thrust
2000N
Max. opening angle
100°
Scope of delivery
Kit includes
2 Operators incl. 2 pair of welding consoles 1 Control unit ST 24 1 Radio receiver RS 868, 2-channel, integrated 2 Transmitters RS 868-4M, 4-channel 1 pair photocells LS180 1 Detailed installation manual
Recommended accessories
Emergency release with profile half cylinder Emergency release optional with profile half cylinder lockable
A 24V battery is optionally available, which guarantees perfect function for approx. 15 cycles in the event of a power failure
Additional limit stop for closed position
Screwable consoles
Safety devices
Radio system
Key switches
The LED starts automatically with the gate movement for more safety
Clear text menu programmable via four buttons in 6 languages: English, German, French, Dutch, Czech, Polish
Save energy! When in standby mode the intelligent control switches off unused devices and thus achieves an extremely low power consumption of only 1 Watt in standby mode! This saves valuable energy.
A high-resolution sensor monitors engine speed and power for maximum safety and comfort.
Clear text menu programmable via four buttons in 8 languages: English, German, Spanish, French, Italian, Dutch, Czech, Polish
